AirTAC AR & BR Series: Modular Pressure Regulators

The AirTAC AR and BR Series are the foundational pressure control components of the AirTAC air preparation line. These regulators utilize a balanced diaphragm design, which provides high-precision pressure setting and excellent pressure stability even when inlet pressures fluctuate.

• AR Series: The compact modular regulator, designed to integrate seamlessly with A-Series filters and lubricators.

• BR Series: A larger-bodied, high-flow regulator designed for primary air lines and compatible with the B-Series modular system.

Key Product Features

• Balanced Structure: High pressure-regulation precision and stability with low "droop" under flow conditions.

• Pressure Relief Function: Standard self-relieving design allows downstream pressure to be exhausted safely through the regulator when the setting is lowered.

• Unique Locking Mechanism: The "push-to-lock" knob prevents accidental pressure adjustments caused by vibration or tampering.

• Modular Flexibility: Can be installed as a standalone unit using a bracket or connected to other FRL components using standard joiner sets.

• Low-Pressure Options: Available in a standard range (0.9 MPa) and a specialized "L" version (0.4 MPa) for delicate applications.
